| Operation System | Android 10.0 |
|---|
| CPU | 64bit Octa-core Cortex-A53 CPU, 2.0GHz |
|---|
| Storage | 4GB RAM / 64GB ROM, Micro SD card (max 256GB expansion) |
|---|
| SDK | PUSH SDK |
|---|
| Display | 5.5 inch IPS Capacitive LCD touch screen |
|---|
| Screen Resolution | 720*1440 |
|---|
| Camera | Dual Lens Rear camera (13 megapixels); Front camera (5 megapixels) |
|---|
| QR Code & Barcode | Dynamic QR codes on the ZKBioSecurity mobile application
QR code, PDF417, Data Matrix, MicroPDF417, Aztec scanning in third-party development projects |
|---|
| Supported Card Type | ISO14443A &15693, NFC-IP1, NFC-IP2 |
|---|
| 3G/4G | TDD LTE Band 38, 39, 40, 41
FDD LTE Band 1, 2, 3, 4, 5, 7, 8,12, 17, 20
WCDMA (850 / 1900 / 2100MHz)
GSM / GPRS / Edge (850 / 900 / 1800 / 1900MHz) |
|---|
| WLAN | 2.4GHz / 5.0GHz Dual Frequency
IEEE 802.11 a / b / g / n / ac |
|---|
| Bluetooth | Bluetooth Class v2.1+EDR
Bluetooth v3.0+HS
Bluetooth v4.2 |
|---|
| GPS | GPS (embedded A-GPS), Glonass (accuracy distance of 5m) |
|---|
| Card Reading Distance (NFC) | 3cm - 5cm max |
|---|
| Biometric Authentications | Face, Fingerprint (Optional) |
|---|
| Facial Recognition Algorithm | ZKFace 5.6.2 |
|---|
| Facial Recognition Distance | 0.3m to 2m |
|---|
| Facial Recognition Speed | < 1s |
|---|
| Facial Recognition Accuracy Rate | ≥ 99% |
|---|
| Fingerprint Sensor Type | Semiconductor |
|---|
| Fingerprint Comparison Time | ≤ 0.5s |
|---|
| User Capacity | 50,000 |
|---|
| Face Capacity | 50,000 |
|---|
| Fingerprint Capacity | 30,000 (Optional) |
|---|
| Card Capacity | 50,000 |
|---|
| Logs Capacity | 1,000,000 |
|---|
| Interface | 1*USB 2.0 Type-C |
|---|
| Protection level | IP65 |
|---|
| Supported Software | ZKBio Time, ZKBio Security, ZKBioCV Security |
|---|
| Firmware Functions | Push, ScheduleBell,Automatic Status Switch, RecordQuery, Groups, Holidays, DST, Workcode, Duress Mode (Password & Fingerprint), Customization of Wallpaper & Screen Saver |
|---|
| Language | English, Korean, Latin American, Indonesian, Vietnamese, Traditional Chinese, Portuguese, Spanish, Farsi, Japanese, Russian and Thai |
|---|
| Power Supply | 5V 2A |
|---|
| Embedded Li-ion Battery | 5200mAh |
|---|
| Casing Material | ABS plastic, tempered glass surface |
|---|
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
|---|
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
|---|
| Working Humidity | <90% RH |
|---|
| Storage Humidity | <90% RH |
|---|
| Operating Environment | Outdoor |
|---|
| Gross Weight | 400g |
|---|
| Weigh with Packaging | 700g |
|---|
| Dimensions (H*W*D) | 170mm * 80mm * 20mm (6.7in * 3.1in * 0.8in) |
|---|
| Certifications | ISO9001, ISO14001, CE, FCC |
|---|
