MK-V1 [ID/IC]
Qty in stockQty per box
Specifications
| Operation System | Linux | Linux |
|---|---|
| Hardware | CPU: CKSF030 RAM: 8KB; ROM: 64KB Touch Keypad: 12 Keys | CPU: CKSF030 RAM: 8KB; ROM: 64KB Touch Keypad: 12 Keys |
| Authentication method | Card / Password | Fingerprint / Card / Password |
| Fingerprint Template Capacity | 1,00 (1:N) (Standard) |
| Card Capacity | 888 (1:N) (Standard) | 888 (1:N) (Standard) |
| Transaction Capacity | 1,000(Standard) | 1,000(Standard) |
| Max. User Password Length | 6 Digits | 6 Digits |
| Card Reading Distance | 2cm to 6cm | 2cm to 6cm |
| Biometric Verification Speed | <0.3s@ Fingerprint |
| False Acceptance Rate (FAR) % | ≤0.001% (Fingerprint Recognition |
| False Rejection Rate (FRR) % | ≤0.1% (Fingerprint Recognition) |
| Card Type | ID & IC (125 kHz & 13.56 MHz Dual Frequency) | ID & IC (125 kHz & 13.56 MHz Dual Frequency) |
| Communication | Wi-Fi (IEEE802.11n/b/g) @ 2.4 GHz Bluetooth: BLE5.0 Wiegand (Input & Output)*1 Aux Inputs *1, Aux Outputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1 | Wi-Fi (IEEE802.11n/b/g) @ 2.4 GHz Bluetooth: BLE5.0 Wiegand (Input & Output)*1 Aux Inputs *1, Aux Outputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1 |
| Standard Function | Access Control, Buzzer, LED (Green: verification successful ; Red: Normal Status ; Blue: verification is in process), Multiple Verification Methods | Access Control, Buzzer, LED (Green: verification successful ; Red: Normal Status ; Blue: verification is in process), Multiple Verification Methods |
| Power Supply | DC 12-18V | DC 12-18V |
| Operating Temperature | 20°C to 60°C | 20°C to 60°C |
| Operating Humidity | 0% to 98% RH (Non-condensing) | 0% to 98% RH (Non-condensing) |
| Dimensions | 165 mm*44 mm*22 mm (L*W*H) | 165 mm*44 mm*22 mm (L*W*H) |
| Gross Weight | 0.500 Kg | 0.500 Kg |
| Net Weight | 0.415 Kg | 0.415 Kg |
| Supported Software | Mobile App: ZSmart (Mobile Credential) | Mobile App: ZSmart (Mobile Credential) |
| Installation | Wall-mount | Wall-mount |
| Ingress Protection Rating | IP66 (waterproof and dustproof ) | IP66 (waterproof and dustproof ) |
| Certifications | ISO9001, ISO14001, CE, RoHS, FCC | ISO9001, ISO14001, CE, RoHS, FCC |
