| Image Sensor | CMOS 1/3" 5MP |
|---|---|
| Lens | 30X Zoom, f = 4.5 ~ 148.5 mm |
| Field of View | 60.1° (Wide) ~ 2.28° (Tele) |
| Scanning System | Progressive |
| Electronic Shutter | Auto/Manual (1/5s – 1/100,000s) |
| Minimum Illumination | 0.05 Lux (color), 0.01 Lux (B/W), 0 Lux with IR on |
| Infrared Range | 7 LED Array + 3 IR Lasers + 2 Warm Strobe Lights, up to 120 m |
| Compression | H.265 / H.264 |
| WDR | DWDR |
| Main Stream | 5 MP @ 25 fps |
| Sub Stream | 640 × 480 @ 25 fps |
| Day/Night Mode | Auto (ICR) / Color / B/W |
| Bitrate Control | CBR / VBR |
| White Balance | Auto / Custom / Locked WB / Incandescent / Warm Light / Natural Light / Fluorescent |
| Primary | 2 Mbps ~ 8 Mbps |
| Secondary | 160 Kbps ~ 896 Kbps |
| PTZ Control | Auto |
| Audio Compression | G.711a / G.711u (32 Kbps) / PCM (128 Kbps) |
| Noise Reduction | 2D & 3D DNR |
| CRH | Supported |
| Privacy Mask | Up to 5 zones |
| Human Detection | Linked with sound/strobe alarm and human detection tracking |
| Audio I/O | Built-in speaker and microphone |
| Max Online Users | 3 |
| ONVIF | ONVIF Profile Supported |
| Supported Browsers | Internet Explorer, Chrome, Firefox |
| Pan Range | 0° ~ 360° |
| Tilt Range | -5° ~ 90° |
| Pan Speed | 0 ~ 180°/s |
| Tilt Speed | 0 ~ 100°/s |
| Presets | 255 |
| Preset Speed Levels | 7 |
| Tour Groups | 8 |
| Pattern Groups | 4 |
| AB Scan Groups | 8 |
| Auto Mode | Supports slow motion, auto power-on detection, proportional zoom optical speed change |
| Protocols Supported | Pelco-D, Pelco-P |
| Protection Level | IP66 |
| Operating Environment | -20 °C to +60 °C, relative humidity < 90% |
| Power Supply | PoE / DC 12V 4A |
| Lightning Protection | ESD 4000V |
| Dimensions | Φ185 × 375 mm |
| Net Weight | 3.5 kg |
| Gross Weight | 4.5 kg |
