| Face Capacity | 30,000 (1:N) ; 100,000 (Optional) |
|---|
| Palm | 5,000 (Customized) |
|---|
| Users / Card Capacity | 50,000 |
|---|
| Transaction Capacity | 1,000,000 (Optional 2,000,000) |
|---|
| User Photo Capacity | 30,000 |
|---|
| Event Photo Capacity | 10,000 |
|---|
| Compatibility | Security Relay BoxWiegand / RS485 Slave Reader with FP / RFID / Barcode / QR-codeSoftware: ZKBio CVSecurityMobile App: ZSmart (Optional) |
|---|
| Hardware | 1GHz Dual Core Customized Computer Vision CPU1G RAM / 8G Flash8" (400lux) IPS Touch LCD125KHz EM Reader / 13.56MHz MF (Optional)2MP WDR Low Light CameraAdjustable Light brightness LEDHi-Fi VoiceMicrophone Distance Detection SensorReset Button and Tamper Switch |
|---|
| Access Control Interface | Lock Relay Output / Alarm Output / Auxiliary Input / Exit Button / Door Sensorr |
|---|
| Special Function | IP68 & IK040.3s High Speed Face VerificationLive Face detectionCommunication Https Encrypted OptionalEvent SnapshotVideo intercomONVIF Protocol (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A)SIP ProtocoI (Compatible with VT07-B01,Optional) |
|---|
| Standard Function | Access Levels, Groups, Holidays, DST, Duress Mode (Password), Anti-Passback, Record Query, Custom Wallpaper & Screen Saver, Tamper Switch Alarm |
|---|
| Communication | TCP / IP / Wiegand Input / Output / Wi-Fi (Optional) / RS485* / RS232* |
|---|
| Algorithm | ZKFace 3.9 & ArmaturaPalm(Customized) |
|---|
| Operating Temperature | -30°C ~ 60°C (-22°F~ 140°F) |
|---|
| Operating Humidity | ≤ 93% |
|---|
| Storage Temperature | -40°C ~ +65°C |
|---|
| Storage Humidity | ≤ 93% |
|---|
| Net Weight | 853 g |
|---|
| Dimension | 227 * 143 * 26 mm (L*W*D) |
|---|
| Operating Voltage | 12V DC |
|---|
| Current Draw | < 2,000 mA |
|---|
