| Model | SenseFace 2A |
|---|
| Display | 2.4"@ TFT Color LCD Screen (320*240) |
|---|
| Camera | WDR Binocular Camera @ 1MP |
|---|
| Operation System | Linux |
|---|
| Hardware | CPU: Dual Core@1GHzRAM: 512MB; ROM: 8GBSpeaker: 8ohm @1W Microphone: *1 (Sensitivity: -32 dB / Omni-directional / Signal-to-Noise Ratio: -32 dB/Impedance: 2.2kΩ)Supplement Light: Yes Physical Keypad: 17 KeysFingerprint Sensor: ZK Optical Sensor |
|---|
| Authentication Method | Fingerprint / Face / Card / Password (Physical Keypad) |
|---|
| Fingerprint Template Capacity | 3,000 (1:N) (Standard) |
|---|
| Face Template Capacity | 1,500 (1:N) (Standard) |
|---|
| Card Capacity | 3,000 (1:N) (Standard) |
|---|
| User Capacity | 3,000 (1:N) (Standard) |
|---|
| Transaction Capacity | 150,000 (1:N) |
|---|
| Max. User Password Length | 8 Digits |
|---|
| Biometric Verification Speed | less than 0.5 sec (Fingerprint)less than 0.35 sec (Facial Authentication) |
|---|
| Touchless Biometric Recognition Distance | 30cm to 200cm (Facial Authentication) |
|---|
| False Acceptance Rate (FAR) % | FAR ≤ 0.01% (Visible Light Facial Authentication) FAR ≤ 0.0001% (Fingerprint) |
|---|
| False Rejection Rate (FRR) % | FRR ≤ 0.02% (Visible Light Facial Authentication)FRR ≤ 0.01% (Fingerprint) |
|---|
| Biometric Algorithm | ZKFace V4.0ZKFingerprint V13.0 (Standard) /V10.0 (Optional) |
|---|
| Card Type | ID Card@125 kHz (Standard) IC Card@13.56 MHz (Optional) |
|---|
| Communication | TCP/IP*1Wi-Fi (IEEE802.11b/g/n/ax) @ 2.4 GHz (Optional)USB: Type A (USB Drive Only )*1Electric Lock*1, Door Sensor*1, Exit Button*1 |
|---|
| Standard Functions | ADMS, DST, Photo Capture, Event Photo Capture, Up to 14-digit User ID, Access Levels, Groups, Holidays, Record Query, Schedule Bell, Tamper Switch Alarm, Automatic Status Switch, Multiple AuthenticationMethods, SIP Client (Version 2.0), ONVIF (Compatible with Profile S, Profile T, Profile G, Profile C, Profile Q & Profile A), AC Push and TA Push Protocol Switch, HTTPs / SSH Backend Access, T9 Keyboard (Input) |
|---|
| Optional Functions | IC Card, Wi-Fi, Wireless Doorbell |
|---|
| Power Supply | DC 12V 1.5A |
|---|
| Video Intercom | Video Intercom (ZKTeco Private Protocol via TCP/lP)Support Devices: Standalone Terminal: SenseFace Series;Indoor Monitor: VT07-B01, VT07-B01-WVideo Intercom (Standard SIP Protocol) Support Devices: Standalone Terminal: SenseFace series; Indoor Monitor: VT07-B22L, VT07-B26L-W; Software: ZKBio CVAccess, BioTalk Pro; Mobile App: ZKBio Zlink, ZKBio Zexus |
|---|
| Operating Temperature | -5°C to 45°C |
|---|
| Operating Humidity | 20% to 80% RH (Non-condensing) |
|---|
| Dimensions | 205.20 mm*74.19 mm*33.30 mm (L*W*H) |
|---|
| Net Weight | 0.258 Kg |
|---|
| Supported Software | On-Premise Software: ZKBio CVAccess (AC PUSH) & ZKBio Time (TA PUSH)Cloud-based Software: ZKBio Zlink (Supports Web Portal & Mobile App) |
|---|
| Installation | Wall-mount (Compatible with Asian Gang Box / Single Gang Box) |
|---|
| Certifications | ISO14001, ISO9001,CE, FCC, RoHS |
|---|
