| Material | Customized water-blocking outer sheath |
|---|---|
| Diameter | 6.3 mm ± 0.5 mm |
| American Wire Gauge | 23AWG |
| Min. Average Thickness | 0.43 mm |
| Color (4 Pairs) | Blue, white / blue; orange, white / orange; green, white / green; brown, white / brown |
| Specification | 500D |
| Color | Black (optional) |
| Max. DC Resistance of a Single Conductor | 9.38Ω/100 m |
| Min. Insulation Resistance | 5000MΩ·km |
| Max. DC Resistance Unbalance | ≤5% |
| Dielectric Strength | No breakdown with 1KV DC for 1 min |
| Characteristic Impedance (1-250MHz) | 100 ± 15Ω |
| Tensile Strength | Sheath≥10 MPa, insulation≥16 MPa |
| Elongation at Break | Sheath≥125%, insulation≥300% |
| Installation Bending Radius | >8 times of outer cable diameter |
| Conductor Elongation at Break | ≥10% |
| Shrinkage of Insulation | ≤5% |
| Color Migration Resistance of Insulation | No migration |
| Sheath Tensile Strength and Elongation at Break after Aging | ≥8 MPa, ≥100% |
| Low Temperature Bending Test | No cracking after the test |
| Heat Shock Test | No cracking after the test |
| Operation Temperature | –20°C to +60°C (–4°F to 140°F) |
| Installation Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature and Humidity | –10°C to +40°C (14°F to 104°F), <60% (RH) |
| Certifications | CPR Eca |
