| Model Name | Comet-S1000Comet-S1200 |
|---|
| Audio Indicator | Internal buzzer |
|---|
| Visual Indicator | LED strip along the lid (7 Colour RGB, Customizable) blue = stand bysteady green = normal usesteady red = door closingflashing red = alarm |
|---|
| Display | 1 or 2*7" IPS touch monitor (Under mount facial recognition version only) |
|---|
| Lane Type | Comet-S1000: Single laneComet-S1200: Dual-wings (with Comet-S1000 only) |
|---|
| Lane Width | 660mm (Standrad)900mm (Optional) |
|---|
| Barrier Movement Type | Swing |
|---|
| Motor | DC brushless motor |
|---|
| Movement Speed | 0.8s per movement(open / Close timing) |
|---|
| Movement Accuracy | ≤1.5 Degree per movement |
|---|
| Clutch | Mechanical clutch for anti-panic / anti-collision |
|---|
| Lid Material | Tempered glass (Black) (Standard) |
|---|
| Lid Options Authentication Methods | Streamlined under mount options: Fingerprint / RFID / QR Code / Fingerprint + RFID / Fingerprint+QR Code / Fingerprint+RFID+QR Code / Facial recognition with display Top mount option: mounting pole (Compatible with ProFace X / SpeedFace V5L/ Elite Pass) |
|---|
| Chassis Material | Cast aluminium alloy (T=3mm) |
|---|
| Chassis Colour | Silver (Standard), gold (Optional) |
|---|
| Door Leaf Material (H*W) | Clear acrylic (630*295mm) (standard)Clear tempered glass (630*295mm) |
|---|
| IR Sensors | 8 Pairs (Standard) (High position) |
|---|
| Motherboard Function | System configuration, access mode configuration, anti-pinch configuration, anti-tailgate configuration etc. |
|---|
| Motherboard Communication | Fire alarm port(relay)*1, RS485 port*1 |
|---|
| Controller | PGIC controller (Standard)Others depends on dimensions fitting in (Optional) |
|---|
| Credential Options | Under mount RFID reader: (support model: ProID series, Armatura EP10C & Armatura EP20 series)under mount QR code reader: QR500under mount fingerprint reader: FR1200 / FR1500under mount facial recognition terminal: G4 ProTop mount facial recogntion terminal: ProFaceX / Elite Pass / SpeedFace V5L |
|---|
| Flow Rate | RFID: 30 passengers per minuteQR Code: 30 passengers per minuteFingerprint: 20 passengers per minuteFace: 15 passengers per minute |
|---|
| Accessibility | Under mount facial recognition version: adult, children, disabilityRest of the versions: adult, children (with care), disability (with care) |
|---|
| Power Supply | 110V / 220V AC @ 50~60Hz |
|---|
| Power Rating | 20 VA (Stand by)120 VA (Operation) |
|---|
| Fire Signal | Input for voltage free contact |
|---|
| Noise Level | Less than 60 dB |
|---|
| MTTR | Less than 60 minutes |
|---|
| MCBF | 6 million |
|---|
| Gross Weight | Comet-S1000: 130kgComet-S1200: 80kg |
|---|
| Net Weight | Comet-S1000: 100kgComet-S1200: 65kg |
|---|
| Dimension (L*W*H) | 1500*115*1000mm (Standard) |
|---|
| Dimensions with Packing ( L*W*H ) | 1600 * 160 * 1200mm |
|---|
| Operating Temperature | -28°C to 60°c |
|---|
| Operating Humidity | 95% RH (non-condensing) |
|---|
| Certifications | CE, FCC |
|---|
| Ingress Protection Rating | N/A (Waterproof and dustproof)N/A (Barrier only) (Vandal ressistant) |
|---|
| Supported Software | ZKEasyGO / ZKBio Access / ZKBio CVSecurity (Depends on equipped access controller) |
|---|
| Safety Features | Safety force sensing Lower safety sensors Accurate presence sensingEmitter/ receiver infrared sensors technologyLogic voltage 24V DCVoltage free contact input for re alarm fail stateAuto opening on power offAnti-panic push opening in operationWide walkway for wheelchair or easier accessAccompanied wheelchair or child passage management (under mount facial recognition version) |
|---|
| Security Features | Anti-intrusion, anti-tailgating, wrong way enter alarm, Automatically close door no one pass |
|---|
| Product Delivery | Pre-assembled |
|---|
| Application Environment | Indoor |
|---|
| Site Preparation | Flat & level finished floor (Base plate in options for unfinished floor) |
|---|
| Security Level | Middle |
|---|
| Emergency Mode | Support (door unlock automatically) |
|---|
| Packing Material | Wooden box |
|---|
