| SpecificationSenseFace M2F-LR |
|---|
| Display2.8" TFT Color LCD, 320 × 240 |
|---|
| CameraBinocular Camera, 1MP |
|---|
| Operating SystemLinux |
|---|
| CPUDual Core @ 1GHz |
|---|
| RAM / ROM512MB / 8GB |
|---|
| Speaker8Ω @ 1W |
|---|
| Physical Keypad16 Keys |
|---|
| Fingerprint SensorZK Optical Sensor |
|---|
| Supplement LightYes |
|---|
| Authentication MethodsFingerprint / Face / Card / Password |
|---|
| Fingerprint Capacity1,000 templates (1:N), Standard |
|---|
| Face Capacity500 templates (1:N), Standard |
|---|
| Card Capacity1,000 cards (1:N), Standard |
|---|
| User Capacity1,000 users, Standard |
|---|
| Transaction Capacity150,000 records |
|---|
| User PasswordUp to 8 digits |
|---|
| Fingerprint Authentication SpeedLess than 1 sec |
|---|
| Facial Authentication SpeedLess than 1.2 sec |
|---|
| Facial Recognition Distance50 cm to 180 cm |
|---|
| FARFingerprint ≤ 0.0001% / Face ≤ 0.02% |
|---|
| FRRFingerprint ≤ 0.1% / Face ≤ 0.05% |
|---|
| Biometric AlgorithmZKFingerprint V13.0 / V10.0 Optional; ZKFace V4.0 |
|---|
| Card TypeID Card 125 kHz Standard / IC Card 13.56 MHz Optional |
|---|
| CommunicationTCP/IP, Wi-Fi 2.4 GHz Optional, USB Type-A |
|---|
| Access ControlElectric Lock / Door Sensor / Exit Button |
|---|
| Standard FunctionsADMS, DST, Photo Capture, Event Photo Capture, Record Query, Schedule Bell, Tamper Alarm, Automatic Status Switch, Multiple Authentication Methods, HTTPS / SSH Backend Access, T9 Keyboard |
|---|
| Backup BatteryOptional 2,000 mAh Lithium Battery |
|---|
| Battery Operating TimeUp to 4 hours |
|---|
| Battery Standby TimeUp to 7 hours |
|---|
| Charging TimeApproximately 5 hours |
|---|
| Power SupplyDC 12V / 1.5A |
|---|
| Operating Temperature-5°C to 45°C |
|---|
| Operating Humidity10% to 90% RH, non-condensing |
|---|
| Dimensions154 × 138 × 34 mm (L × W × H) |
|---|
| Net Weight0.43 kg |
|---|
| Gross Weight1.03 kg |
|---|
| Supported SoftwareZKBio Zlink / ZKBio Time |
|---|
| InstallationWall-mount; compatible with Asian Gang Box / Single Gang Box |
|---|
| CertificationsISO14001, ISO9001, CE, FCC, RoHS |
|---|
