| Display | 5" Touch Screen |
|---|
| Face Capacity | 6,000 (Optional:10,000) |
|---|
| Palm Capacity | 3,000 (Customized) |
|---|
| Card Capacity | 10,000 |
|---|
| Transaction Capacity | 200,000(Optional: 500k) |
|---|
| Operation System | Linux |
|---|
| Functions | ID Card, ADMS, DNS, T9 Input, DST, Camera, 9-digit User ID, Advance Access Control, Groups, Holidays, Anti-passback, Record Query, Tamper Switch Alarm, Bell Scheduling, POE (Optional, IEEE 802.3at-2009) |
|---|
| Hardware | 1GHz Dual Core CPU / 1G RAM / 8G Flash / 2MP WDR Low Light Camera / Adjustable LED Supplement Lighting / Rain Cover (Optional) |
|---|
| Communication | TCP / IP, Wi-Fi (Optional), Wiegand Input / Output, RS485* |
|---|
| Access Control Interface | 3rd-party Electric Lock, Door Sensor, Exit Button, Alarm Output, Aux. Input |
|---|
| Optional Card Module | IC / HID / iClass / Felica / Desfire EV1 / EV2 / Legic |
|---|
| Facial Recognition Speed | ≤ 0.5s per face |
|---|
| Biometrics Algorithm | ZKFace V3.9 & ArmaturaPalm (Customized) |
|---|
| Ingress Protection Rating | IP66 |
|---|
| Power Supply | Voltage: DC 12V Current: Max. 3A |
|---|
| Operating Humidity | 10% to 90% |
|---|
| Operating Temperature | -10°C to 50°C |
|---|
| Dimension | 103.83 * 212.41 * 50.60 (mm) (W*H*D) |
|---|
| Supported Software | ZKBio CVAccess |
|---|
