| Weight | 1.8kg |
|---|---|
| Dimensions | 308.5 * 308.5 * 67.5 |
| OutputPower | 19dBm - 30dBm |
| Power | 1.2 - 4.2W |
| Frequency | F: 902MHz - 906MHz (adjustable) |
| CommunicationInterface | Wiegand, RS485, USB configuration parameters (Wiegand, RS485 requires one of two options) |
| InterfaceProtocol | EPC global UHF Class 1 Gen 2 / ISO 18000-6C |
| WorkingMode | Read Always (Default) and Read by Trigger |
| ProtectionLevel | IP66 |
| WorkingVoltage | DC 9 - 15V |
| StorageTemperatureandHumidity | -20°C - 80°C, < 85% |
| RS485Communication | Optional baud rate (9600, 19200, 38400, 57600, 115200), the default is 115200 |
