| Dimensions (L*W*H) | 167.3*70.5*81.5 (mm) |
|---|
| Weight | 165g |
|---|
| Voltage & Current | 5 VDC Operating: 90mA (Standby: 30mA) |
|---|
| Color | Black and Gray (White, optional) |
|---|
| Support Host Interface | 2.4GHz (2.4GHz+Bluetooth, optional) |
|---|
| User Indicators | Decode LED Indicator; Beeper (adjustable tone and volume) |
|---|
| Scan Mode | Manual Reading Mode |
|---|
| Light Source | 620nm Red light |
|---|
| Scan Speed | 50ms/time |
|---|
| Minimum Print Contrast | 25% |
|---|
| Roll Tolerance | ±30° |
|---|
| Pitch Tolerance | ±65° |
|---|
| Skew Tolerance | ±60° |
|---|
| Decode Capability | 1D: UPC-A, UPC-E, EAN-8, EAN-13, ISSN, ISBN, Code 128, ISBT 128, Code 39, Code 93, Code 11, Interleaved 2 of 5, Matrix 2 of 5, Industrial 2 of 5, Standard 2 of 5 (IATA), Codabar (NW-7) |
|---|
| Radio Range | 2.4GHz: 60m (Bluetooth: 15m) |
|---|
| Wireless Communication Mode | Synchronous Mode; Storage Mode |
|---|
| Battery Type | 18650 Li-ion Battery |
|---|
| Battery Capacity | 2000 mAh |
|---|
| Operating Time Per Full Charge | ≥15 Hours |
|---|
| Standby Time Per Full Charge | ≥10 Weeks |
|---|
| Charge Time (from Empty)/ Standard USB | 5 Hours |
|---|
| Operating Temperature | -20°C to 50°C |
|---|
| Storage Temperature | -40°C to 70°C |
|---|
| Humidity | 5% to 95% relative humidity, non-condensing |
|---|
| Electrostatic Discharge (ESD) | ±2KV Direct; ±8KV Air |
|---|
| Ambient Light Immunity | 10000 Lux Max |
|---|
| Symbology / Resolution | Near / Far |
|---|
| Code 39: 4 mil | 3 cm to 10 cm |
|---|
| Code 39: 5 mil | 3 cm to 13 cm |
|---|
| Code 39: 13 mil | 4 cm to 30 cm |
|---|
| Code 39: 20 mil | 6 cm to 40 cm |
|---|
| EAN-13: 13 mil | 3 cm to 30 cm |
|---|
| UPC-A: 13 mil | 3 cm to 30 cm |
|---|
